Production Data
WM8352
13.9 ANALOGUE OUTPUTS
13.9.1 OUT1L AND OUT1R
The headphone outputs, OUT1L and OUT1R can drive a 16Ω or 32Ω headphone load, either through
DC blocking capacitors, or DC coupled without any capacitor. Each output has an analogue volume
control PGA with a gain range of -57dB to +6dB as shown in Figure 44.
Common mode noise rejection is also possible on the OUT1L and OUT1R outputs, using HPCOM as
the return path. The HPCOM feature must be enabled via the OUT1_FB register field and the
HPCOM connection must be AC coupled to the headphone output. A 4.7uF coupling capacitor is
required between the noisy ground connection the HPCOM pin.
The control register fields for the OUT1L and OUT1R outputs are described in Table 40. The
available output configurations are shown in Section 13.9.3.
OUT1L_MUTE
R104 [14]
From left
output mixer
OUT1L
-1
OUT1L_VOL
R104 [7:2]
OUT1R_MUTE
R105 [14]
From right
output mixer
OUT1R
-1
OUT1R_VOL
R105 [7:2]
HPCOM
Vmid
OUT1_FB
R76 [0]
Figure 44 Headphone Outputs OUT1L and OUT1R
PD, February 2011, Rev 4.4
83
