The gain for microphone pre-amp and auxiliary input (IN3L/IN3R) signals can be independently
adjusted for each output mixer. This does not affect the volume of the same signals going into the
separate record mixer. The level of the DAC output signals can be adjusted using the DAC’s digital
volume control function (see Table 32).
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
R96 (60h)
3:1
INL_MIXOUTL_VOL
[2:0]
000
Left input PGA volume control to left
output mixer.
Output Left
Mixer
Volume
000 = Path disabled (disconnected)
001 = -12dB gain through mixer
010 = -9dB gain through mixer
…
111 = +6dB gain through mixer
7:5
INR_MIXOUTL_VO
L [2:0]
000
000
000
000
000
Right input PGA volume control to left
output mixer.
000 = Path disabled (disconnected)
001 = -12dB gain through mixer
010 = -9dB gain through mixer
…
111 = +6dB gain through mixer
11:9 IN3L_MIXOUTL_VO
L [2:0]
IN3L amplifier volume control to left
output mixer
000 = Path disabled (disconnected)
001 = -12dB gain through mixer
010 = -9dB gain through mixer
…
111 = +6dB gain through mixer
R97 (61h)
3:1
INL_MIXOUTR_VO
L [2:0]
Left input PGA volume control to right
output mixer.
Output Right
Mixer
Volume
000 = Path disabled (disconnected)
001 = -12dB gain through mixer
010 = -9dB gain through mixer
…
111 = +6dB gain through mixer
7:5
INR_MIXOUTR_VO
L [2:0]
Right input PGA volume control to
right output mixer.
000 = Path disabled (disconnected)
001 = -12dB gain through mixer
010 = -9dB gain through mixer
…
111 = +6dB gain through mixer
15:1 IN3R_MIXOUTR_V
OL [2:0]
IN3R amplifier volume control to right
output mixer.
3
000 = Path disabled (disconnected)
001 = -12dB gain through mixer
010 = -9dB gain through mixer
…
111 = +6dB gain through mixer
Table 39 Controlling the Gain of Signals Going into the Output Mixers
PD, February 2011, Rev 4.4
