Production Data
WM8352
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
0 = VRTC is not driven out on SWVRTC pin
1 = VRTC is driven out on SWVRTC pin
Reset by state machine.
AUXADC control
7
3
2
1
0
AUXADC_ENA
DCMP4_ENA
DCMP3_ENA
DCMP2_ENA
DCMP1_ENA
0
0
0
0
0
0 = disabled
1 = enabled
Reset by state machine.
Digital comparator 4 enable
0 = disabled
1 = enabled
Reset by state machine.
Digital comparator 3 enable
0 = disabled
1 = enabled
Reset by state machine.
Digital comparator 2 enable
0 = disabled
1 = enabled
Reset by state machine.
Digital comparator 1 enable
0 = disabled
1 = enabled
Reset by state machine.
Register 0Ch Power mgmt (5)
REGISTER
ADDRESS
BIT
LABEL
DEFAULT
DESCRIPTION
REFER TO
R13 (0Dh)
Power mgmt
(6)
15
LS_ENA
0
Limit Switch enable
0 = disabled
1 = enabled
Note: internal conditions may prevent the converter
from actually switching on - see DCDC/LDO Status
register for actual converter status.
Reset by state machine. Default held in metal mask.
11
10
9
LDO4_ENA
LDO3_ENA
LDO2_ENA
0
0
0
LDO4 enable
0 = disabled
1 = enabled
Note: internal conditions may prevent the converter
from actually switching on - see DCDC/LDO Status
register for actual converter status.
Reset by state machine. Default held in metal mask.
LDO3 enable
0 = disabled
1 = enabled
Note: internal conditions may prevent the converter
from actually switching on - see DCDC/LDO Status
register for actual converter status.
Reset by state machine. Default held in metal mask.
LDO2 enable
0 = disabled
1 = enabled
Note: internal conditions may prevent the converter
from actually switching on - see DCDC/LDO Status
register for actual converter status.
Reset by state machine. Default held in metal mask.
PD, February 2011, Rev 4.4
227
