TPS929160-Q1
ZHCSNG0 – APRIL 2023
www.ti.com.cn
图 7-142. FLAG_SHORT0 Register
7
6
5
4
3
2
1
0
RESERVED
FLAG_SHORT FLAG_SHORT
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
OUTB1
OUTB0
OUTA1
OUTA0
R-0h
R-0h
R-0h
R-0h
R-0h
表 7-150. FLAG_SHORT0 Register Field Descriptions
Bit
7-6
5
Field
Type
Reset
Description
RESERVED
R
0h
Reserved
FLAG_SHORTOUTB1
R
0h
Output short-circuit fault flag for OUTB1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
4
FLAG_SHORTOUTB0
R
0h
Output short-circuit fault flag for OUTB0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_SHORTOUTA1
Output short-circuit fault flag for OUTA1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
0
FLAG_SHORTOUTA0
R
0h
Output short-circuit fault flag for OUTA0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
7.6.5.13 FLAG_SHORT1 Register (Offset = ACh) [Reset = 00h]
FLAG_SHORT1 is shown in 图 7-143 and described in 表 7-151.
Return to the Summary Table.
图 7-143. FLAG_SHORT1 Register
7
6
5
4
3
2
1
0
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
RESERVED
R-0h
FLAG_SHORT FLAG_SHORT
OUTD1
OUTD0
OUTC1
OUTC0
R-0h
R-0h
R-0h
R-0h
表 7-151. FLAG_SHORT1 Register Field Descriptions
Bit
Field
Type
Reset
Description
7-6
5
RESERVED
R
0h
Reserved
FLAG_SHORTOUTD1
R
0h
Output short-circuit fault flag for OUTD1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
4
FLAG_SHORTOUTD0
R
0h
Output short-circuit fault flag for OUTD0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
3-2
1
RESERVED
R
R
0h
0h
Reserved
FLAG_SHORTOUTC1
Output short-circuit fault flag for OUTC1
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
0
FLAG_SHORTOUTC0
R
0h
Output short-circuit fault flag for OUTC0
0h = Output short-circuit fault is not detected.
1h = Output short-circuit fault is detected.
7.6.5.14 FLAG_SHORT2 Register (Offset = ADh) [Reset = 00h]
FLAG_SHORT2 is shown in 图 7-144 and described in 表 7-152.
