Bits
Field Name
Description
Type
Reset
7:6
Reserved
Reserved bit
RO
R returns
0s
0x0
5
4
THERM_HD
Hot die detector output:
when 0: the hot die threshold is not reached
when 1: the hot die threshold is reached
RO
RO
RW
0
0
THERM_TS
Thermal shutdown detector output:
when 0: the thermal shutdown threshold is not reached
when 1: the thermal shutdown threshold is reached
3:2
THERM_HDSEL
Temperature selection for Hot Die detector:
when 00: Low temperature threshold
…
0x3
when 11: High temperature threshold
1
0
RSVD1
Reserved bit
RW
RW
0
1
THERM_STATE
Thermal shutdown module enable signal:
when 0: thermal shutdown module is disable
when 1: thermal shutdown module is enable
Table 60. BBCH_REG
Address Offset
Physical Address
Description
Type
0x39
Instance
Back-up battery charger control register
RW
7
6
5
4
3
2
1
0
Reserved
BBSEL
BBCHEN
Bits
Field Name
Description
Type
Reset
7:4
Reserved
Reserved bit
RO
R returns
0s
0x00
2:1
0
BBSEL
Back up battery charge voltage selection:
BBSEL[1:0] = 00 : 3.0 V
BBSEL[1:0] = 01 : 2.52 V
BBSEL[1:0] = 10 : 3.15 V
BBSEL[1:0] = 11 : VBAT
RW
0x0
0
BBCHEN
Back up battery charge enable
RW
Table 61. DCDCCTRL_REG
Address Offset
Physical Address
Description
Type
0x3E
Instance
DCDC control register
RW
7
6
5
4
3
2
DCDCCKEXT
1
0
Reserved
VDD2_PSKIP
VDD1_PSKIP
VIO_PSKIP
DCDCCKSYNC
Bits
Field Name
Description
Type
Reset
7:6
Reserved
Reserved bit
RO
R returns
0s
0x0
5
4
3
VDD2_PSKIP
VDD1_PSKIP
VIO_PSKIP
VDD2 pulse skip mode enable (EEPROM bit)
VDD1 pulse skip mode enable (EEPROM bit)
VIO pulse skip mode enable (EEPROM bit)
RW
RW
RW
1
1
1
