Bits
Field Name
Description
Type
Reset
7:4
Reserved
Reserved bit
RO
R returns
0s
0x0
(1)
3:2
1:0
SEL
ST
Supply voltage (EEPROM bits):
SEL[1:0] = 00 : 1.8 V
SEL[1:0] = 01 : 2.0 V
SEL[1:0] = 10 : 2.8 V
SEL[1:0] = 11 : 3.3 V
RW
See
Supply state (EEPROM bits):
ST[1:0] = 00 : Off
RW
0x0
ST[1:0] = 01 : On high power (ACTIVE)
ST[1:0] = 10 : Off
ST[1:0] = 11 : On low power (SLEEP)
(1) The reset value for this field varies with boot mode selection and the processor support. Please refer to the corresponding processor
user guide to find the correct default value.
Table 56. VMMC_REG
Address Offset
Physical Address
Description
Type
0x35
Instance
VMMC regulator control register
RW
7
6
5
4
3
2
1
0
Reserved
SEL
ST
Bits
Field Name
Description
Type
Reset
7:4
Reserved
Reserved bit
RO
R returns
0s
0x0
(1)
3:2
1:0
SEL
Supply voltage (EEPROM bits):
SEL[1:0] = 00 : 1.8 V
SEL[1:0] = 01 : 2.8 V
SEL[1:0] = 10 : 3.0 V
SEL[1:0] = 11 : 3.3 V
RW
See
ST
Supply state (EEPROM bits):
ST[1:0] = 00: Off
RW
0x0
ST[1:0] = 01: On high power (ACTIVE)
ST[1:0] = 10: Off
ST[1:0] = 11: On low power (SLEEP)
(1) The reset value for this field varies with boot mode selection and the processor support. Please refer to the corresponding processor
user guide to find the correct default value.
Table 57. VPLL_REG
Address Offset
Physical Address
Description
Type
0x36
Instance
VPLL regulator control register
RW
7
6
5
4
3
2
1
0
Reserved
SEL
ST
