TPS65910, TPS65910A, TPS65910A3, TPS659101, TPS659102, TPS659103
TPS659104, TPS659105, TPS659106, TPS659107, TPS659108, TPS659109
SWCS046N –MARCH 2010–REVISED APRIL 2012
www.ti.com
7
6
5
4
3
2
1
0
Reserved
Reserved
ST
Bits
Field Name
Description
Type
Reset
7:4
Reserved
Reserved bit
RO
R returns
0s
0x0
3
VRTC_OFFMASK
VRTC internal regulator off mask signal:
RW
0
when 1, the regulator keeps its full-load capability during device OFF
state.
when 0, the regulator will enter in low-power mode during device OFF
state.(EEPROM bit)
2
Reserved
ST
Reserved bit
RO
R returns
0s
0
1:0
Reference state:
RO
0x1
ST[1:0] = 00 : Reserved
ST[1:0] = 01 : On high power (ACTIVE)
ST[1:0] = 10 : Reserved
ST[1:0] = 11 : On low power (SLEEP)
(Write access available in test mode only)
Table 43. VIO_REG
Address Offset
Physical Address
Description
Type
0x20
Instance
VIO control register
RW
7
6
5
4
3
2
1
0
ILMAX
Reserved
SEL
ST
Bits
Field Name
Description
Type
Reset
7:6
ILMAX
Select maximum load current:
when 00: 0.5 A
RW
0x0
when 01: 1.0 A
when 10: 1.0 A
when 11: 1.0 A
5:4
3:2
Reserved
SEL
Reserved bit
RO
R returns
0s
0x0
(1)
Output voltage selection (EEPROM bits):
SEL[1:0] = 00 : 1.5 V
RW
See
SEL[1:0] = 01 : 1.8 V
SEL[1:0] = 10 : 2.5 V
SEL[1:0] = 11 : 3.3 V
1:0
ST
Supply state (EEPROM bits):
ST[1:0] = 00 : Off
RW
0x0
ST[1:0] = 01 : On high power (ACTIVE)
ST[1:0] = 10 : Off
ST[1:0] = 11 : On low power (SLEEP)
(Write access available in test mode only)
(1) The reset value for this field varies with boot mode selection and the processor support. Please refer to the corresponding processor
user guide to find the correct default value.
64
Submit Documentation Feedback
Copyright © 2010–2012, Texas Instruments Incorporated
Product Folder Link(s): TPS65910 TPS65910A TPS65910A3 TPS659101 TPS659102 TPS659103 TPS659104
TPS659105 TPS659106 TPS659107 TPS659108 TPS659109
