6.19 Timers
The DM6437 device has 3 64-bit general-purpose timers which have the following features:
•
•
64-bit count-up counter
Timer modes:
–
–
–
64-bit general-purpose timer mode (Timer 0 and 1)
Dual 32-bit general-purpose timer mode (Timer 0 and 1)
Watchdog timer mode (Timer 2)
•
•
2 possible clock sources:
–
–
Internal clock
External clock input via timer input pin TINPL (Timer 0 and 1 only)
2 operation modes:
–
–
One-time operation (timer runs for one period then stops)
Continuous operation (timer automatically resets after each period)
•
•
•
Generates interrupts to the DSP
Generates sync event to EDMA
Causes device global reset upon watchdog timer timeout (Timer 2 only)
For more detailed information, see Section 2.9, Documentation Support for the TMS320DM643x DMP
64-Bit Timer User's Guide (literature number SPRU989).
6.19.1 Timer Peripheral Register Description(s)
Table 6-92. Timer 0 Registers
HEX ADDRESS RANGE
0x01C2 1400
ACRONYM
DESCRIPTION
-
Reserved
0x01C2 1404
EMUMGT_CLKSPD
Timer 0 Emulation Management/Clock Speed Register
Timer 0 Counter Register 12
Timer 0 Counter Register 34
Timer 0 Period Register 12
Timer 0 Period Register 34
Timer 0 Control Register
0x01C2 1410
TIM12
TIM34
PRD12
PRD34
TCR
0x01C2 1414
0x01C2 1418
0x01C2 141C
0x01C2 1420
0x01C2 1424
TGCR
-
Timer 0 Global Control Register
Reserved
0x01C2 1428 - 0x01C2 17FF
Table 6-93. Timer 1 Registers
HEX ADDRESS RANGE
0x01C2 1800
ACRONYM
DESCRIPTION
-
Reserved
0x01C2 1804
EMUMGT_CLKSPD
Timer 1 Emulation Management/Clock Speed Register
Timer 1 Counter Register 12
Timer 1 Counter Register 34
Timer 1 Period Register 12
Timer 1 Period Register 34
Timer 1 Control Register
0x01C2 1810
TIM12
TIM34
PRD12
PRD34
TCR
0x01C2 1814
0x01C2 1818
0x01C2 181C
0x01C2 1820
0x01C2 1824
TGCR
-
Timer 1 Global Control Register
Reserved
0x01C2 1828 - 0x01C2 1BFF
