TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
6.10.2.4 DAC Electrical Data/Timing
Table 6-46. Switching Characteristics Over Recommended Operating Conditions for DAC Static
Specifications
-400
-500
-600
NO.
PARAMETER
TEST CONDITIONS
UNIT
MIN
TYP
MAX
DC Accuracy
Integral Non-Linearity (INL)
Differential Non-Linearity (DNL)
-1.0
-0.5
1.0
0.5
LSB
LSB
Analog Output
Offset Error
Gain Error
0.5
5
500
LSB
%FS
mVPP
Full-Scale Output Voltage
RLOAD = 500 Ω
Output Capacitance
200
pF
Reference
Reference Voltage Range (VREF
Full-Scale Current Adjust Resistor (RBIAS)
0.475
3.8
0.5
4.0
0.525
4.2
V
kΩ
)
Table 6-47. Switching Characteristics Over Recommended Operating Conditions for DAC Dynamic
Specifications
-400
-500
-600
NO.
PARAMETER
TEST CONDITIONS
UNIT
MIN
TYP
MAX
Output Update Rate (FCLK
)
27
6
60
MHz
MHz
Signal Bandwidth
FCLK = 27 MHz
FOUT = 2.0 MHz
FCLK = 60 MHz
FOUT = 2.0 MHz
FCLK = 27 MHz
FOUT = 2.0 MHz
FCLK = 60 MHz
FOUT = 2.0 MHz
60
60
60
60
dB
dB
db
SFDR to Nyquist
SFDR within Bandwidth
dB
dB
PSRR Over Temp vs Power Supply
50
Submit Documentation Feedback
Peripheral Information and Electrical Specifications
