TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
Table 6-7. DM6437 EDMA Registers (continued)
HEX ADDRESS
0x01C0 0380
0x01C0 0384
0x01C0 0388
0x01C0 038C
0x01C0 0390 - 0x01C0 039C
0x01C0 0400
0x01C0 0404
0x01C0 0408
0x01C0 040C
0x01C0 0410
0x01C0 0414
0x01C0 0418
0x01C0 041C
0x01C0 0420
0x01C0 0424
0x01C0 0428
0x01C0 042C
0x01C0 0430
0x01C0 0434
0x01C0 0438
0x01C0 043C
0x01C0 0440
0x01C0 0444
0x01C0 0448
0x01C0 044C
0x01C0 0450
0x01C0 0454
0x01C0 0458
0x01C0 045C
0x01C0 0460
0x01C0 0464
0x01C0 0468
0x01C0 046C
0x01C0 0470
0x01C0 0474
0x01C0 0478
0x01C0 047C
0x01C0 0480
0x01C0 0484
0x01C0 0488
0x01C0 048C
0x01C0 0490
0x01C0 0494
0x01C0 0498
0x01C0 049C
0x01C0 04A0
0x01C0 04A4
ACRONYM
QRAE0
QRAE1
QRAE2
QRAE3
–
REGISTER NAME
QDMA Region Access Enable Register for Region 0
QDMA Region Access Enable Register for Region 1
QDMA Region Access Enable Register for Region 2
QDMA Region Access Enable Register for Region 3
Reserved
Q0E0
Q0E1
Q0E2
Q0E3
Q0E4
Q0E5
Q0E6
Q0E7
Q0E8
Q0E9
Q0E10
Q0E11
Q0E12
Q0E13
Q0E14
Q0E15
Q1E0
Q1E1
Q1E2
Q1E3
Q1E4
Q1E5
Q1E6
Q1E7
Q1E8
Q1E9
Q1E10
Q1E11
Q1E12
Q1E13
Q1E14
Q1E15
Q2E0
Q2E1
Q2E2
Q2E3
Q2E4
Q2E5
Q2E6
Q2E7
Q2E8
Q2E9
Event Q0 Entry 0 Register
Event Q0 Entry 1 Register
Event Q0 Entry 2 Register
Event Q0 Entry 3 Register
Event Q0 Entry 4 Register
Event Q0 Entry 5 Register
Event Q0 Entry 6 Register
Event Q0 Entry 7 Register
Event Q0 Entry 8 Register
Event Q0 Entry 9 Register
Event Q0 Entry 10 Register
Event Q0 Entry 11 Register
Event Q0 Entry 12 Register
Event Q0 Entry 13 Register
Event Q0 Entry 14 Register
Event Q0 Entry 15 Register
Event Q1 Entry 0 Register
Event Q1 Entry 1 Register
Event Q1 Entry 2 Register
Event Q1 Entry 3 Register
Event Q1 Entry 4 Register
Event Q1 Entry 5 Register
Event Q1 Entry 6 Register
Event Q1 Entry 7 Register
Event Q1 Entry 8 Register
Event Q1 Entry 9 Register
Event Q1 Entry 10 Register
Event Q1 Entry 11 Register
Event Q1 Entry 12 Register
Event Q1 Entry 13 Register
Event Q1 Entry 14 Register
Event Q1 Entry 15 Register
Event Q2 Entry 0 Register
Event Q2 Entry 1 Register
Event Q2 Entry 2 Register
Event Q2 Entry 3 Register
Event Q2 Entry 4 Register
Event Q2 Entry 5 Register
Event Q2 Entry 6 Register
Event Q2 Entry 7 Register
Event Q2 Entry 8 Register
Event Q2 Entry 9 Register
178
Peripheral Information and Electrical Specifications
Submit Documentation Feedback
TI [ TEXAS INSTRUMENTS ]
