TMS320DM6437
Digital Media Processor
www.ti.com
SPRS345B–NOVEMBER 2006–REVISED MARCH 2007
Table 6-7. DM6437 EDMA Registers (continued)
HEX ADDRESS
ACRONYM
Transfer Controller 0 Registers
REGISTER NAME
0x01C1 0000
0x01C1 0004
-
TCCFG
-
Reserved
EDMA3 TC0 Configuration Register
Reserved
0x01C1 0008 - 0x01C1 00FF
0x01C1 0100
TCSTAT
-
EDMA3 TC0 Channel Status Register
Reserved
0x01C1 0104 - 0x01C1 0110
0x01C1 0114 - 0x01C1 011F
0x01C1 0120
-
Reserved
ERRSTAT
ERREN
ERRCLR
ERRDET
ERRCMD
-
EDMA3 TC0 Error Status Register
EDMA3 TC0 Error Enable Register
EDMA3 TC0 Error Clear Register
EDMA3 TC0 Error Details Register
EDMA3 TC0 Error Interrupt Command Register
Reserved
0x01C1 0124
0x01C1 0128
0x01C1 012C
0x01C1 0130
0x01C1 0134 - 0x01C1 013F
0x01C1 0140
RDRATE
-
EDMA3 TC0 Read Command Rate Register
Reserved
0x01C1 0144 - 0x01C1 01FF
0x01C1 0200 - 0x01C1 023F
0x01C1 0240
-
Reserved
SAOPT
SASRC
SACNT
SADST
SABIDX
SAMPPRXY
SACNTRLD
SASRCBREF
SADSTBREF
-
EDMA3 TC0 Source Active Options Register
EDMA3 TC0 Source Active Source Address Register
EDMA3 TC0 Source Active Count Register
EDMA3 TC0 Source Active Destination Address Register
EDMA3 TC0 Active B-Index Register
0x01C1 0244
0x01C1 0248
0x01C1 024C
0x01C1 0250
0x01C1 0254
EDMA3 TC0 Source Active Memory Protection Proxy Register
EDMA3 TC0 Source Active Count Reload Register
EDMA3 TC0 Source Active Source Address B-Reference Register
EDMA3 TC0 Source Active Destination Address B-Reference Register
Reserved
0x01C1 0258
0x01C1 025C
0x01C1 0260
0x01C1 0264 - 0x01C1 027F
0x01C1 0280
DFCNTRLD
DFSRCBREF
EDMA3 TC0 Destination FIFO Set Count Reload Register
EDMA3 TC0 Destination FIFO Set Source Address B-Reference Register
0x01C1 0284
EDMA3 TC0 Destination FIFO Set Destination Address B-Reference
Register
0x01C1 0288
DFDSTBREF
0x01C1 028C - 0x01C1 02FF
0x01C1 0300
-
Reserved
DFOPT0
DFSRC0
DFCNT0
DFDST0
DFBIDX0
DFMPPRXY0
-
EDMA3 TC0 Destination FIFO Options Register 0
EDMA3 TC0 Destination FIFO Source Address Register 0
EDMA3 TC0 Destination FIFO Count Register 0
EDMA3 TC0 Destination FIFO Destination Address Register 0
EDMA3 TC0 Destination FIFO B-Index Register 0
EDMA3 TC0 Destination FIFO Memory Protection Proxy Register 0
Reserved
0x01C1 0304
0x01C1 0308
0x01C1 030C
0x01C1 0310
0x01C1 0314
0x01C1 0318 - 0x01C1 033F
0x01C1 0340
DFOPT1
DFSRC1
DFCNT1
DFDST1
DFBIDX1
DFMPPRXY1
-
EDMA3 TC0 Destination FIFO Options Register 1
EDMA3 TC0 Destination FIFO Source Address Register 1
EDMA3 TC0 Destination FIFO Count Register 1
EDMA3 TC0 Destination FIFO Destination Address Register 1
EDMA3 TC0 Destination FIFO B-Index Register 1
EDMA3 TC0 Destination FIFO Memory Protection Proxy Register 1
Reserved
0x01C1 0344
0x01C1 0348
0x01C1 034C
0x01C1 0350
0x01C1 0354
0x01C1 0358 - 0x01C1 037F
0x01C1 0380
DFOPT2
DFSRC2
EDMA3 TC0 Destination FIFO Options Register 2
EDMA3 TC0 Destination FIFO Source Address Register 2
0x01C1 0384
182
