TMS320C6678
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS691D—April 2013
www.ti.com
Table 7-43
CIC0/CIC1 Register
Address Offset
0x818
Register Mnemonic
HINT_MAP_REG6
HINT_MAP_REG7
HINT_MAP_REG8
HINT_MAP_REG9
HINT_MAP_REG10
HINT_MAP_REG11
HINT_MAP_REG12
HINT_MAP_REG13
HINT_MAP_REG14
HINT_MAP_REG15
HINT_MAP_REG16
HINT_MAP_REG17
HINT_MAP_REG18
ENABLE_HINT_REG0
ENABLE_HINT_REG1
ENABLE_HINT_REG2
Register Name
Host Interrupt Map Register for 24 to 24+3
Host Interrupt Map Register for 28 to 28+3
Host Interrupt Map Register for 32 to 32+3
Host Interrupt Map Register for 36 to 36+3
Host Interrupt Map Register for 40 to 40+3
Host Interrupt Map Register for 44 to 44+3
Host Interrupt Map Register for 48 to 48+3
Host Interrupt Map Register for 52 to 52+3
Host Interrupt Map Register for 56 to 56+3
Host Interrupt Map Register for 60 to 60+3
Host Interrupt Map Register for 64 to 64+3
Host Interrupt Map Register for 68 to 68+3
Host Interrupt Map Register for 72 to 72+3
Host Int Enable Register 0
0x81c
0x820
0x824
0x828
0x82c
0x830
0x834
0x838
0x83c
0x840
0x844
0x848
0x1500
0x1504
0x1508
Host Int Enable Register 1
Host Int Enable Register 2
End of Table 7-43
7.9.2.2 CIC2 Register Map
Table 7-44
CIC2 Register
Address Offset
0x0
Register Mnemonic
Register Name
REVISION_REG
Revision Register
0x10
GLOBAL_ENABLE_HINT_REG
STATUS_SET_INDEX_REG
STATUS_CLR_INDEX_REG
ENABLE_SET_INDEX_REG
ENABLE_CLR_INDEX_REG
HINT_ENABLE_SET_INDEX_REG
HINT_ENABLE_CLR_INDEX_REG
RAW_STATUS_REG0
RAW_STATUS_REG1
RAW_STATUS_REG2
RAW_STATUS_REG3
RAW_STATUS_REG4
ENA_STATUS_REG0
ENA_STATUS_REG1
ENA_STATUS_REG2
ENA_STATUS_REG3
ENA_STATUS_REG4
ENABLE_REG0
Global Host Int Enable Register
Status Set Index Register
Status Clear Index Register
Enable Set Index Register
Enable Clear Index Register
Host Int Enable Set Index Register
Host Int Enable Clear Index Register
Raw Status Register 0
Raw Status Register 1
Raw Status Register 2
Raw Status Register 3
Raw Status Register 4
Enabled Status Register 0
Enabled Status Register 1
Enabled Status Register 2
Enabled Status Register 3
Enabled Status Register 4
Enable Register 0
0x20
0x24
0x28
0x2c
0x34
0x38
0x200
0x204
0x208
0x20c
0x210
0x280
0x284
0x288
0x28c
0x290
0x300
0x304
0x308
0x30c
ENABLE_REG1
Enable Register 1
ENABLE_REG2
Enable Register 2
ENABLE_REG3
Enable Register 3
Copyright 2013 Texas Instruments Incorporated
Peripheral Information and Electrical Specifications 183
