TMS320C6672
Multicore Fixed and Floating-Point Digital Signal Processor
SPRS708C—February 2012
www.ti.com
Table 3-17
Timer Input Selection Field Description (TINPSEL) (Part 2 of 2)
Description
Bit
Field
TINPLSEL4
20
Input select for TIMER4 low.
0 = TIMI0
1 = TIMI1
19
18
17
16
TINPHSEL3
TINPLSEL3
TINPHSEL2
TINPLSEL2
Input select for TIMER3 high.
0 = TIMI0
1 = TIMI1
Input select for TIMER3 low.
0 = TIMI0
1 = TIMI1
Input select for TIMER2 high.
0 = TIMI0
1 = TIMI1
Input select for TIMER2 low.
0 = TIMI0
1 = TIMI1
15-4 Reserved
Reserved
3
2
1
0
TINPHSEL1
TINPLSEL1
TINPHSEL0
TINPLSEL0
Input select for TIMER1 high.
0 = TIMI0
1 = TIMI1
Input select for TIMER1 low.
0 = TIMI0
1 = TIMI1
Input select for TIMER0 high.
0 = TIMI0
1 = TIMI1
Input select for TIMER0 low.
0 = TIMI0
1 = TIMI1
