TCA6424A
SCPS193B –JULY 2010–REVISED SEPTEMBER 2010
www.ti.com
PARAMETER MEASUREMENT INFORMATION (continued)
Pn
500 W
DUT
2 ´ V
CCP
C
= 50 pF
L
500 W
(see Note A)
P PORT LOAD CONFIGURATION
0.7 ´ V
0.3 ´ V
CCP
CCI
SCL
P0
A
P3
Slave
ACK
SDA
Pn
t
pv
(see Note B)
Last Stable Bit
Unstable
Data
WRITE MODE (R/W = 0)
0.7 ´ V
0.3 ´ V
CCI
CCI
SCL
P0
A
P3
t
ph
t
ps
Pn
0.5 ´ V
CCP
READ MODE (R/W = 1)
A. CL includes probe and jig capacitance.
B. tpv is measured from 0.7 × VCC on SCL to 50% I/O (Pn) output.
C. All inputs are supplied by generators having the following characteristics: PRR ≤ 10 MHz, ZO = 50 Ω, tr/tf ≤ 30 ns.
D. The outputs are measured one at a time, with one transition per measurement.
E. All parameters and waveforms are not applicable to all devices.
Figure 12. P-Port Load Circuit and Timing Waveforms
