RM46L450
RM46L850
www.ti.com
SPNS184 –SEPTEMBER 2012
4.6.1.1.1 Timing Requirements for Main Oscillator
Table 4-9. Timing Requirements for Main Oscillator
Parameter
MIN
50
Type
MAX
200
Unit
ns
tc(OSC)
Cycle time, OSCIN (when using a sine-wave input)
tc(OSC_SQR)
Cycle time, OSCIN, (when input to the OSCIN is a
square wave )
12.5
200
ns
tw(OSCIL)
tw(OSCIH)
Pulse duration, OSCIN low (when input to the OSCIN
is a square wave)
15
15
ns
ns
Pulse duration, OSCIN high (when input to the OSCIN
is a square wave)
