PGA281
www.ti.com
SBOS664A –MARCH 2013–REVISED JUNE 2013
ELECTRICAL CHARACTERISTICS (continued)
At TA = +25°C, VSP = +15 V, VSN = –15 V, VSON = 0 V, VSOP = 5 V, DVDD = +3 V, RL = 2.5 kΩ to VSOP / 2 = VOCM,
G = 1 V/V, VCM = 0 V, and differential output, unless otherwise noted.
PGA281
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
DIGITAL I/O (Supply = 2.7 V to 5.5 V)
Logic low threshold
0.1
0.2(DVDD)
DVDD
V
V
G4:G0 pin input
Logic high threshold
0.8(DVDD)
G4:G0 pin input current
Error flag (EF pin) output
0.2
μA
V
Logic low, disable
0.7
Logic high, alarm
DVDD – 0.5
V
Alarm → disable (recovery)
Disable → alarm (response)
5
μs
μs
Error flag (EF pin) delay
30
POWER SUPPLY: Input Stage (VSP – VSN)
Specified voltage range
TA = –40°C to +105°C
10 (±5)
10 (±5)
36 (±18)
V
V
Operating voltage range
38 (±19)
IQ(VSP)
IQ(VSN)
Quiescent current , VSP pin
Quiescent current, VSN pin
TA = –40°C to +105°C
TA = –40°C to +105°C
2.4
2.1
3
3
mA
mA
POWER SUPPLY: Output Stage (VSOP – VSON)
Specified voltage range
VSP – 1.5 V ≥ VSOP, TA = –40°C to +105°C
2.7
5.5
V
V
Voltage range for VSOP, upper
limit
(VSP – 2 V) > VOCM, (VSP – 5 V) > VSON
(VSP)
0.75
Voltage range for VSON
(VSP – 2 V) > VOCM, VSP ≥ VSOP
(VSN)
(VSP) – 5
1
V
IQ(VSOP)
Quiescent current, VSOP pin
TA = –40°C to +105°C
mA
POWER SUPPLY: Digital (DVDD – VSON)
Specified voltage range
TA = –40°C to +105°C
2.7
5.5
V
V
Voltage range for DVDD, upper
limit
(VSP) – 1
(VSN)
Voltage range for VSON, lower
limit
V
Static condition, no external load, DVDD = 3 V,
TA = –40°C to +105°C
IQ(DVDD)
Quiescent current(11)
0.07
0.13
mA
TEMPERATURE
Specified range
Operating range
–40
–55
+105
+140
°C
°C
(11) See Application Information section and Typical Characteristic graphs.
