Register 2Ch, INT0 Output Register
(Address: 2Ch, Read-Only)
DATA
B7
B6
ONPCM0
N/A
B5
OEMPHF0
N/A
B4
ODTSCD0
N/A
B3
OCSRNW0
N/A
B2
OPCRNW0
N/A
B1
OFSCHG0
N/A
B0
RSV
0
Reg Name
Default Value
Memo
OERROR0
N/A
OERROR0: ERROR Port Output Status
0: No ERROR
1: Detect ERROR
This register setting follows the register setting of the ERROR factor.
ONPCM0: NPCM Port Output Status
0: PCM data
1: Non-PCM data
This register setting follows the register setting of non-PCM data identification.
OEMPHF0: Emphasis Flag in Channel Status
0: No emphasis
1: Emphasis
ODTSCD0: DTS-CD/LD Detection
0: No DTS-CD/LD
1: DTS-CD/LD
This register setting follows the register setting for DTS-CD/LD detection conditions.
OCSRNW0: Channel Status Data of Beginning 48-bit Renewal
0: Not detect renewal
1: Detect renewal
OPCRNW0: Burst Preamble PC Renewal
0: Not detect renewal
1: Detect renewal
OFSCHG0: Renewal Flag of fS Calculator Result
0: Not detect renewal
1: Detect renewal
When this register is read, the INT0 output is cleared.
