PCM9211
SBAS495 –JUNE 2010
www.ti.com
Register 78h, MPO1, MPO0 Function Assign Setting
(Address: 78h, Write and Read)
DATA
B7
B6
MPO1SEL2
0
B5
MPO1SEL1
1
B4
MPO1SEL0
1
B3
MPO0SEL3
1
B2
MPO0SEL2
1
B1
MPO0SEL1
0
B0
MPO0SEL0
1
Reg Name
Default Value
Memo
MPO1SEL3
0
MPO1SEL[3:0]: MPO1 Pin, Output Control
0000: Hi-Z
0001: GPO, Output data = High level
0010: GPO, Output data = Low level
0011: VOUT (default)
0100: INT0
0101: INT1
0110: CLKST
0111: EMPH
1000: BPSYNC
1001: DTSCD
1010: PARITY
1011: LOCK
1100: XMCKO
1101: TXOUT
1110: RECOUT0
1111: RECOUT1
MPO0SEL[3:0]: MPO0 Pin, Output Control
0000: Hi-Z
0001: GPO, Output data = High level
0010: GPO, Output data = Low level
0011: VOUT
0100: INT0
0101: INT1
0110: CLKST
0111: EMPH
1000: BPSYNC
1001: DTSCD
1010: PARITY
1011: LOCK
1100: XMCKO
1101: TXOUT (default)
1110: RECOUT0
1111: RECOUT1
