PCM9211
SBAS495 –JUNE 2010
www.ti.com
Register 7Ch, GPIO Output Data Setting for MPIO_C
(Address: 7Ch, Write and Read)
DATA
Reg Name
Default Value
Memo
B7
RSV
0
B6
RSV
0
B5
RSV
0
B4
RSV
0
B3
GPOC3
0
B2
GPOC2
0
B1
GPOC1
0
B0
GPOC0
0
GPOC3: MPIO_C3 Pin, GPIO Output Data Setting
0: Output low level (default)
1: Output high level
GPOC2: MPIO_C2 Pin, GPIO Output Data Setting
0: Output low level (default)
1: Output high level
GPOC1: MPIO_C1 Pin, GPIO Output Data Setting
0: Output low level (default)
1: Output high level
GPOC0: MPIO_C0 Pin, GPIO Output Data Setting
0: Output low level (default)
1: Output high level
These registers are effective only as GPIOs are assigned to output.
114
Submit Documentation Feedback
Copyright © 2010, Texas Instruments Incorporated
Product Folder Link(s): PCM9211
