MSP430F530x, MSP430F5310
www.ti.com
SLAS677B –SEPTEMBER 2010–REVISED MARCH 2011
Table 37. 32-Bit Hardware Multiplier Registers (Base Address: 04C0h)
REGISTER DESCRIPTION
REGISTER
OFFSET
16-bit operand 1 – multiply
MPY
00h
02h
04h
06h
08h
0Ah
0Ch
0Eh
10h
12h
14h
16h
18h
1Ah
1Ch
1Eh
20h
22h
24h
26h
28h
2Ah
2Ch
16-bit operand 1 – signed multiply
16-bit operand 1 – multiply accumulate
16-bit operand 1 – signed multiply accumulate
16-bit operand 2
MPYS
MAC
MACS
OP2
16 × 16 result low word
RESLO
RESHI
16 × 16 result high word
16 × 16 sum extension register
SUMEXT
MPY32L
MPY32H
MPYS32L
MPYS32H
MAC32L
MAC32H
MACS32L
MACS32H
OP2L
32-bit operand 1 – multiply low word
32-bit operand 1 – multiply high word
32-bit operand 1 – signed multiply low word
32-bit operand 1 – signed multiply high word
32-bit operand 1 – multiply accumulate low word
32-bit operand 1 – multiply accumulate high word
32-bit operand 1 – signed multiply accumulate low word
32-bit operand 1 – signed multiply accumulate high word
32-bit operand 2 – low word
32-bit operand 2 – high word
OP2H
32 × 32 result 0 – least significant word
32 × 32 result 1
RES0
RES1
32 × 32 result 2
RES2
32 × 32 result 3 – most significant word
MPY32 control register 0
RES3
MPY32CTL0
