Table 36. Real-Time Clock Registers (Base Address: 04A0h)
REGISTER DESCRIPTION
REGISTER
RTCCTL0
OFFSET
RTC control 0
00h
01h
02h
03h
08h
0Ah
0Ch
0Dh
0Eh
10h
11h
12h
13h
14h
15h
16h
17h
18h
19h
1Ah
1Bh
RTC control 1
RTCCTL1
RTC control 2
RTCCTL2
RTC control 3
RTCCTL3
RTC prescaler 0 control
RTC prescaler 1 control
RTC prescaler 0
RTC prescaler 1
RTC interrupt vector word
RTCPS0CTL
RTCPS1CTL
RTCPS0
RTCPS1
RTCIV
RTC seconds/counter register 1
RTC minutes/counter register 2
RTC hours/counter register 3
RTC day of week/counter register 4
RTC days
RTCSEC/RTCNT1
RTCMIN/RTCNT2
RTCHOUR/RTCNT3
RTCDOW/RTCNT4
RTCDAY
RTC month
RTCMON
RTC year low
RTCYEARL
RTCYEARH
RTCAMIN
RTC year high
RTC alarm minutes
RTC alarm hours
RTCAHOUR
RTCADOW
RTCADAY
RTC alarm day of week
RTC alarm days
