MSP430F530x, MSP430F5310
SLAS677B –SEPTEMBER 2010–REVISED MARCH 2011
www.ti.com
Table 25. SYS Registers (Base Address: 0180h)
REGISTER DESCRIPTION
REGISTER
SYSCTL
OFFSET
System control
00h
02h
06h
08h
0Ah
0Ch
0Eh
18h
1Ah
1Ch
1Eh
Bootstrap loader configuration area
JTAG mailbox control
SYSBSLC
SYSJMBC
SYSJMBI0
SYSJMBI1
SYSJMBO0
SYSJMBO1
SYSBERRIV
SYSUNIV
JTAG mailbox input 0
JTAG mailbox input 1
JTAG mailbox output 0
JTAG mailbox output 1
Bus Error vector generator
User NMI vector generator
System NMI vector generator
Reset vector generator
SYSSNIV
SYSRSTIV
Table 26. Shared Reference Registers (Base Address: 01B0h)
REGISTER DESCRIPTION
REGISTER
REFCTL
OFFSET
OFFSET
Shared reference control
00h
Table 27. Port Mapping Registers
(Base Address of Port Mapping Control: 01C0h, Port P4: 01E0h)
REGISTER DESCRIPTION
REGISTER
PMAPPWD
Port mapping password register
Port mapping control register
Port P4.0 mapping register
Port P4.1 mapping register
Port P4.2 mapping register
Port P4.3 mapping register
Port P4.4 mapping register
Port P4.5 mapping register
Port P4.6 mapping register
Port P4.7 mapping register
00h
02h
00h
01h
02h
03h
04h
05h
06h
07h
PMAPCTL
P4MAP0
P4MAP1
P4MAP2
P4MAP3
P4MAP4
P4MAP5
P4MAP6
P4MAP7
30
