MSP430F530x, MSP430F5310
SLAS677B –SEPTEMBER 2010–REVISED MARCH 2011
www.ti.com
DMA Controller
The DMA controller allows movement of data from one memory address to another without CPU intervention. For
example, the DMA controller can be used to move data from the ADC10_A conversion register to RAM. Using
the DMA controller can increase the throughput of peripheral modules. The DMA controller reduces system
power consumption by allowing the CPU to remain in sleep mode, without having to awaken to move data to or
from a peripheral.
(1)
Table 12. DMA Trigger Assignments
Channel
Trigger
0
1
2
0
DMAREQ
DMAREQ
DMAREQ
1
TA0CCR0 CCIFG
TA0CCR2 CCIFG
TA1CCR0 CCIFG
TA1CCR2 CCIFG
TA2CCR0 CCIFG
TA2CCR2 CCIFG
TB0CCR0 CCIFG
TB0CCR2 CCIFG
Reserved
TA0CCR0 CCIFG
TA0CCR2 CCIFG
TA1CCR0 CCIFG
TA1CCR2 CCIFG
TA2CCR0 CCIFG
TA2CCR2 CCIFG
TB0CCR0 CCIFG
TB0CCR2 CCIFG
Reserved
TA0CCR0 CCIFG
TA0CCR2 CCIFG
TA1CCR0 CCIFG
TA1CCR2 CCIFG
TA2CCR0 CCIFG
TA2CCR2 CCIFG
TB0CCR0 CCIFG
TB0CCR2 CCIFG
Reserved
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
UCA0RXIFG
UCA0TXIFG
UCB0RXIFG
UCB0TXIFG
UCA1RXIFG
UCA1TXIFG
UCB1RXIFG
UCB1TXIFG
UCA0RXIFG
UCA0TXIFG
UCB0RXIFG
UCB0TXIFG
UCA1RXIFG
UCA1TXIFG
UCB1RXIFG
UCB1TXIFG
UCA0RXIFG
UCA0TXIFG
UCB0RXIFG
UCB0TXIFG
UCA1RXIFG
UCA1TXIFG
UCB1RXIFG
UCB1TXIFG
(2)
(2)
(2)
ADC10IFG0
ADC10IFG0
ADC10IFG0
Reserved
Reserved
reserved
reserved
MPY ready
DMA2IFG
DMAE0
Reserved
Reserved
reserved
reserved
MPY ready
DMA0IFG
DMAE0
Reserved
Reserved
reserved
reserved
MPY ready
DMA1IFG
DMAE0
(1) If a reserved trigger source is selected, no Trigger1 is generated.
(2) Only on devices with ADC. Reserved on devices without ADC.
