Figure 51. +5V to +12V Boost Regulator
Table 3 contains a table of standard inductors, by part number and corresponding manufacturer, for the fixed
output regulator of Figure 51.
Table 3. Inductor Selection Table
(1)
(2)
Coilcraft
R4793-A
Pulse
PE-53900
Renco(3)
Schott(4)
RL-5472-5
67146520
(1) Coilcraft Inc.,: Phone: (800) 322-26451102 Silver Lake Road, Cary, IL 60013: Fax: (708) 639-1469
(2) Pulse Engineering Inc.,: Phone: (619) 674-810012220 World Trade Drive, San Diego, CA 92128: Fax: (619) 674-8262
(3) Renco Electronics Inc.,: Phone: (800) 645-582860 Jeffryn Blvd. East, Deer Park, NY 11729: Fax: (516) 586-5562
(4) Schott Corp.,: Phone: (612) 475-11731000 Parkers Lane Road, Wayzata, MN 55391: Fax: (612) 475-1786
Figure 52. +12V to +24V Boost Regulator
Figure 53. +24V to +36V Boost Regulator
