DLPA2000
ZHCSCO5B –JUNE 2014–REVISED FEBRUARY 2018
www.ti.com.cn
7.5.23 User EEPROM, BYTE4
Figure 38. User EEPROM, BYTE4, Address = 24h, HEX = 00
7
6
5
4
3
2
1
0
BYTE4 [39:32]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset.
Table 34. User EEPROM, BYTE4 Field Descriptions
BIT
FIELD
TYPE
R/W
RESET
DESCRIPTION
39:32
BYTE4
00000000 USER BYTE 4
7.5.24 User EEPROM, BYTE5
Figure 39. User EEPROM, BYTE5, Address = 25h, HEX = 00
7
6
5
4
3
2
1
0
BYTE5 [47:40]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset.
Table 35. User EEPROM, BYTE5 Field Descriptions
BIT
FIELD
TYPE
R/W
RESET
DESCRIPTION
47:40
BYTE5
00000000 USER BYTE 5
7.5.25 User EEPROM, BYTE6
Figure 40. User EEPROM, BYTE6, Address = 26h, HEX = 00
7
6
5
4
3
2
1
0
BYTE6 [55:48]
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset.
Table 36. User EEPROM, BYTE6 Field Descriptions
BIT
FIELD
TYPE
R/W
RESET
DESCRIPTION
55:48
BYTE6
00000000 USER BYTE 6
7.5.26 User EEPROM, BYTE7
Figure 41. User EEPROM, BYTE7, Address = 27h, HEX = 00
7
6
5
4
3
2
1
0
BYTE7 [63:56]
R
R
R
R
R
R
R
R
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset.
Table 37. User EEPROM, BYTE7 Field Descriptions
BIT
FIELD
TYPE
RESET
DESCRIPTION
63:56
BYTE7
R
00000000 USER BYTE 7
40
