CC1110Fx / CC1111Fx
Notice that the DMA triggers I2SRX and
ADC_CH6 share the same DMA trigger
number (# 27) in the same way as I2STX and
ADC_CH7 share DMA trigger number 28. This
means that I2SRX can not be used together
with ADC_CH6 and I2STX can not be used
together with ADC_CH7. On the CC1111Fx ADC
channels 6 and 7 cannot be used since P0_6
and P0_7 I/O pins are not available.
located in the I2SSTAT register. The interrupt
enables and flags are summarized below.
Interrupt enable bits:
I2S RX: I2SCFG0.RXIEN
I2S TX: I2SCFG0.TXIEN
Interrupt flags:
I2S RX: I2SSTAT.RXIRQ
I2S TX: I2SSTAT.TXIRQ
Refer to Table 51 on Page 107 for an overview
of the DMA triggers.
The TX interrupt flag I2SSTAT.TXIRQ is
asserted together with IRCON2.I2STXIF
when the internal TX buffer is empty and the
I2S fetches the new data previously written to
the I2SDATH:I2SDATL registers. The TX
interrupt flag, I2SSTAT.TXIRQ, is cleared
when I2SDATHregister is written. An interrupt
12.15.4 Underflow/Overflow
If the I2S attempts to read from the internal TX
buffer when it is empty, an underflow condition
occurs. The I2S will then continue to read from
the
data
in
the
TX
buffer,
and
I2SSTAT.TXUNFwill be asserted.
request
is
only
generated
when
If the I2S attempts to write to the internal RX
buffer while it is full, an overflow condition
occurs. The contents of the RX buffer will be
overwritten and the I2SSTAT.RXOVF flag will
be asserted.
I2SCFG0.TXIEN and IEN2.I2STXIE are
both set to 1.
The RX interrupt flag I2SSTAT.RXIRQ is
asserted together with TCON.I2SRXIF when
the internal RX buffer is full and the contents of
the RX buffer is copied to the pair of internal
data registers that can be read from the
Thus, when debugging an application,
software may check for underflow/overflow
when an interrupt is generated or when the
application completes. The TXUNF / RXOVF
flags should be cleared in software.
I2SDATH:I2SDATL
registers.
The
RX
interrupt flag, I2SSTAT.RXIRQ, is cleared
when the I2SDATH register is read. An
interrupt request is only generated when
I2SCFG0.RXIEN and IEN0.I2SRXIE are
both set to 1.
12.15.5 Writing a Word (TX)
When each sample fits into a single byte or µ-
Law compressed samples (always 8 bits) are
written, i.e. µ-Law expansion is enabled
(I2SCFG0.ULAWE=1), only the I2SDATH
register needs to be written.
Notice that interrupts will also be generated if
the corresponding RXIRQ or TXIRQ flags are
set from software, given that the interrupts are
enabled.
The I2S shares interrupt vector with USART 1,
and the ISR must take this into account if both
modules are used. Refer to 10.5 on Page 60
for more details about interrupts.
When each sample is more than 8 bits the low
byte must be written to the I2SDATL register
before the high byte is written to the I2SDATH
register, hence writing the I2SDATH register
indicates the completion of the write operation.
12.15.3 I2S DMA Triggers
When the I2S is configured to send stereo, i.e.
I2SCFG0.TXMONO is 0, the I2SSTAT.TXLR
flag can be used to determine whether the left-
or right-channel sample is to be written to the
data registers.
There are two DMA triggers associated with
the I2S interface, I2SRXand I2STX. The DMA
triggers are activated by RX complete and TX
complete events, i.e. the same events that can
generated the I2S interrupt requests. The DMA
triggers are not masked by the interrupt enable
bits, I2SCFG0.RXIEN and I2SCFG0.TXIEN,
hence a DMA channel can be configured to
use the I2S receive/transmit data registers,
I2SDATH:I2SDATL, as source or destination
address and let RX and TX complete trigger
the DMA.
12.15.6 Reading a Word (RX)
If each sample fits into a single byte or if µ-Law
compression is enabled (I2SCFG0.ULAWC=1),
only the I2SDATH register needs to be read.
When each sample is more than 8 bits the low
byte must be read from the I2SDATL register
before the high byte is being read from the
SWRS033H
Page 163 of 246
