9.2 Typical Application
This section describes a typical battery management system (BMS) application circuit using the ADS131M04-
Q1. The device serves the following primary functions in this BMS:
• Measure battery current with high resolution and accuracy using a low-side current shunt sensor
• Measure peak currents and detect overcurrent or short-circuit conditions
• Measure battery-pack voltage using a high-voltage resistor divider
图9-4 shows the front-end for the battery management system circuit design.
PACK+
AVDD = 3.3 V
DVDD = 3.3 V
AVDD
DVDD
1 μF
1 μF
Device
RH1
RH2
RH3
AIN0P
AIN0N
CLKIN
DRDY
Battery Pack Voltage
Measurement
RL
CS
SCLK
DIN
DOUT
SYNC/RESET
AIN1P
AIN1N
Current Shunt
Measurement
CAP
220 nF
PACK-
AGND
DGND
RSHUNT
图9-4. ADS131M04-Q1 in a Typical Battery Management System Application
9.2.1 Design Requirements
表9-2. Design Requirements
DESIGN PARAMETER
Current Measurement
Current measurement range
Current shunt value
Update rate
VALUE
±5 kA
35 μΩ
1 ms
Battery-Pack Voltage Measurement
Voltage measurement range
0 V to 800 V
