Table 4. Timer feature comparison (continued)
DMA
request
generatio
n
Max
Max
Counter
Timer resolutio
n
Capture/
compare
channels
Timer
type
Counter Prescaler
Complementar interface timer
type
factor
y output
clock
(MHz) (MHz)
clock
Up,
Down,
Up/dow
n
Anyinteger
between 1
and 65536
TIM2,
32-bit
TIM5
Yes
Yes
4
4
No
42
42
84
84
Up,
Down,
Up/dow
n
Anyinteger
between 1
and 65536
TIM3,
16-bit
TIM4
No
Anyinteger
between 1
and 65536
TIM9
16-bit
16-bit
16-bit
16-bit
16-bit
Up
Up
Up
Up
Up
No
No
No
No
Yes
2
1
2
1
0
No
No
No
No
No
84
84
42
42
42
168
168
84
General
purpose
TIM10
,
TIM11
Anyinteger
between 1
and 65536
Anyinteger
between 1
and 65536
TIM12
TIM13
,
TIM14
Anyinteger
between 1
and 65536
84
Anyinteger
between 1
and 65536
TIM6,
TIM7
Basic
84
Advanced-control timers (TIM1, TIM8)
The advanced-control timers (TIM1, TIM8) can be seen as three-phase PWM generators
multiplexed on 6 channels. They have complementary PWM outputs with programmable
inserted dead times. They can also be considered as complete general-purpose timers.
Their 4 independent channels can be used for:
•
•
•
•
Input capture
Output compare
PWM generation (edge- or center-aligned modes)
One-pulse mode output
If configured as standard 16-bit timers, they have the same features as the general-purpose
TIMx timers. If configured as 16-bit PWM generators, they have full modulation capability (0-
100%).
The advanced-control timer can work together with the TIMx timers via the Timer Link
feature for synchronization or event chaining.
TIM1 and TIM8 support independent DMA request generation.
