32 Mbit Concurrent SuperFlash
SST36VF3203 / SST36VF3204
Data Sheet
TABLE 10: D
EVICE
G
EOMETRY
I
NFORMATION
Address
x16 Mode
27H
28H
29H
2AH
2BH
2CH
2DH
2EH
2FH
30H
31H
32H
33H
34H
Address
x8 Mode
4EH
50H
52H
54H
56H
58H
5AH
5CH
5EH
60H
62H
64H
66H
68H
Data
1
0016H
0002H
0000H
0000H
0000H
0002H
003FH
0000H
0000H
0001H
00FFH
0003H
0010H
0000H
Description
Device size = 2
N
Bytes (16H = 22; 2
22
= 4 MByte)
Flash Device Interface description; 0002H = x8/x16 asynchronous interface
Maximum number of bytes in multi-byte write = 2
N
(00H = not supported)
Number of Erase Sector/Block sizes supported by device
Block Information (y + 1 = Number of blocks; z x 256B = block size)
y = 63 + 1 = 64 blocks (003FH = 63)
z = 256 x 256 Bytes = 64 KByte/block (0100H = 256)
Sector Information (y + 1 = Number of sectors; z x 256B = sector size)
y = 1023 + 1 = 1024 sectors (03FFH = 1023)
z = 16 x 256 Bytes = 4 KByte/sector (0010H = 16)
T10.2 1270
1. In x8 mode, only the lower byte of data is output.
©2005 Silicon Storage Technology, Inc.
S71270-03-000
7/06
15
