Table 20. Device Geometry Definition
Addresses
(x16)
Data
Description
Device Size = 2N byte
27h
00xxh
0017h = 64 Mb, 0016h = 32Mb
Flash Device Interface description (refer to CFI publication 100)
28h
29h
000xh
0000h
0000h = x8-only bus devices
0001h = x16-only bus devices
0002h = x8/x16 bus devices
2Ah
2Bh
0005h
0000h
Max. number of byte in multi-byte write = 2N
(00h = not supported)
Number of Erase Block Regions within device (01h = uniform device,
02h = boot device)
2Ch
00xxh
Erase Block Region 1 Information
2Dh
2Eh
2Fh
30h
00xxh
000xh
00x0h
000xh
(refer to the CFI specification or CFI publication 100)
007Fh, 0000h, 0020h, 0000h = 32 Mb (-R1, -R2)
003Fh, 0000h, 0001h = 32 Mb (-R3, R4)
007Fh, 0000h, 0020h, 0000h = 64 Mb (-R1, -R2, -R8, -R9)
007Fh, 0000h, 0000h, 0001h = 64 Mb (-R3, -R4, -R5, -R6, -R7)
31h
32h
33h
34h
00xxh
0000h
0000h
000xh
Erase Block Region 2 Information (refer to CFI publication 100)
003Eh, 0000h, 0000h, 0001h = 32 Mb (-R1, -R2)
007Eh, 0000h, 0000h, 0001h = 64 Mb (-R1, -R2, -R8, -R9)
0000h, 0000h, 0000h, 0000h = all others
35h
36h
37h
38h
0000h
0000h
0000h
0000h
Erase Block Region 3 Information (refer to CFI publication 100)
Erase Block Region 4 Information (refer to CFI publication 100)
39h
3Ah
3Bh
3Ch
0000h
0000h
0000h
0000h
42
S71GL032A Based MCPs
