DC PARAMETERS
MAXIMUM GUARANTEED RATINGS
Operating Temperature Range........................................................................................................................... 0oC to +70oC
Storage Temperature Range............................................................................................................................-55o to +150oC
Lead Temperature Range (soldering, 10 seconds)..................................................................................................... +325oC
Positive Voltage on any pin, with respect to Ground (Note 1) ...................................................................................Vcc+0.3V
Negative Voltage on any pin, with respect to Ground......................................................................................................-0.3V
Maximum Vcc...................................................................................................................................................................+3.6V
Note 1: Maximum voltage on all I type Inputs and the IS inputs, OD12 and OD24 outputs for floppy disk drive interface is
5.25V
*Stresses above the specified parameters could cause permanent damage to the device. This is a stress rating only and
functional operation of the device at any other condition above those indicated in the operation sections of this
specification is not implied.
Note 2: When powering this device from laboratory or system power supplies, it is important that the Absolute Maximum
Ratings not be exceeded or device failure can result. Some power supplies exhibit voltage spikes on their outputs when
the AC power is switched on or off. In addition, voltage transients on the AC power line may appear on the DC output.
When this possibility exists, it is suggested that a clamp circuit be used.
DC ELECTRICAL CHARACTERISTICS (TA = 0°C - 70°C, Vcc = +3.3 V ± 10%)
PARAMETER
SYMBOL
MIN
TYP
MAX
UNITS
COMMENTS
I Type Input Buffer
VILI
VIHI
0.8
V
V
TTL Levels
Low Input Level
2.0
High Input Level
ICLK Input Buffer
VILCK
VIHCK
0.4
V
V
Low Input Level
2.2
High Input Level
Input Leakage
(All I and IS buffers)
IIL
-10
-10
+10
+10
uA
uA
VIN = 0
Low Input Leakage
IIH
VIN = VCC
High Input Leakage
O8 Type Buffer
VOL
VOH
IOL
0.4
V
V
IOL = 8 mA
Low Output Level
High Output Level
2.4
-10
IOH = -4 mA
+10
0.4
UA
VIN = 0 to VCC (Note 1)
Output Leakage
I/O8(P) Type Buffer
VOL
VOH
V
V
IOL = 8mA
Low Output Level
High Output Level
Output Leakage IO8
2.4
IOH = -4mA
IOL
IOL
-10
-50
+10
+10
µA
µA
VIN = 0 to Vcc (Note 1)
VIN = 0 to Vcc (Note 1)
IO8P
