REG OFFSET
NAME
DESCRIPTION
(Type)
Force Disk Change
0x18
Force Disk Change
Bit[0] Force Disk Change for FDC0
Default = 0x01 on
VCC POR
(R/W)
0=Inactive
1=Active
Bit[1] Reserved
Force Change 0 can be written to 1 but is not clearable by
software. Force Change 0 is cleared on nSTEP and
nDS0
DSKCHG (FDC DIR Register, Bit 7) = (nDS0 AND Force
Change 0) OR nDSKCHG
Setting the Force Disk Change bit active ‘1’ forces the
FDD nDSKCHG input active.
Bit[7:2] Reserved
Floppy Data Rate
Select Shadow
0x19
(R)
Floppy Data Rate Select Shadow
Bit[0] Data Rate Select 0
Bit[1] Data Rate Select 1
Bit[2] PRECOMP 0
Bit[3] PRECOMP 1
Bit[4] PRECOMP 2
Bit[5] Reserved
Bit[6] Power Down
Bit[7] Soft Reset
UART1 FIFO
0x1A
(R)
UART FIFO Control Shadow 1
Bit[0] FIFO Enable
Control Shadow
Bit[1] RCVR FIFO Reset
Bit[2] XMIT FIFO Reset
Bit[3] DMA Mode Select
Bit[5:4] Reserved
Bit[6] RCVR Trigger (LSB)
Bit[7] RCVR Trigger (MSB)
Interrupt Generating Register 1 (Note 2)
0=Corresponding Interrupt frame driven low in the SER
IRQ stream. This must be enabled through the INT_G
Configuration Register.
Bit[0] Reserved
INT_GEN1
0x1B
Default = 0xFF
on VCC POR and
HARD RESET
(R/W)
Bit[1] nINT1
Bit[2] nINT2
Bit[3] nINT3
Bit[4] nINT4
Bit[5] nINT5
Bit[6] nINT6
Bit[7] nINT7
Note: To enable/disable this register see Logical
Device A (0xF1)
