Advanced I/O Controller with Motherboard GLUE Logic
Datasheet
7.25.12 Soft Power Down Mode
This mode is entered by executing a HALT instruction. The execution of program code is halted until
either RESET is driven active or a data byte is written to the DBBIN register by a master CPU. If this
mode is exited using the interrupt, and the IBF interrupt is enabled, then program execution resumes with
a CALL to the interrupt routine, otherwise the next instruction is executed. If it is exited using RESET then
a normal reset sequence is initiated and program execution starts from program memory location 0.
7.25.13 Hard Power Down Mode
This mode is entered by executing a STOP instruction. The oscillator is stopped by disabling the
oscillator driver cell. When either RESET is driven active or a data byte is written to the DBBIN register
by a master CPU, this mode will be exited (as above). However, as the oscillator cell will require an
initialization time, either RESET must be held active for sufficient time to allow the oscillator to stabilize.
Program execution will resume as above.
7.25.14 Interrupts
The LPC47M182 provides the two 8042 interrupts: IBF and the Timer/Counter Overflow.
7.25.15 Memory Configurations
The LPC47M182 provides 2K of on-chip ROM and 256 bytes of on-chip RAM.
7.25.16 Register Definitions
Host I/F Data Register
The Input Data register and Output Data register are each 8 bits wide. A write to this 8 bit register will load
the Keyboard Data Read Buffer, set the OBF flag and set the KIRQ output if enabled. A read of this
register will read the data from the Keyboard Data or Command Write Buffer and clear the IBF flag. Refer
to the KIRQ and Status register descriptions for more information.
Host I/F Status Register
The Status register is 8 bits wide.
Table 7.12 shows the contents of the Status register.
Table 7.12 - Status Register
D7
UD
D6
UD
D5
UD
D4
UD
D3
C/D
D2
UD
D1
IBF
D0
OBF
Status Register
This register is cleared on a reset. This register is read-only for the Host and read/write by the LPC47M182
CPU.
UD
Writable by LPC47M182 CPU. These bits are user-definable.
SMSC LPC47M182
121
Revision 1.8 SMSC/Non-SMSC Register Sets (02-24-05)
DATASHEET
