Table 74 – MPU-401 [Logical Device Number = 0x0B]
REG INDEX DEFINITION
NAME
Base I/O Address
Low Byte
STATE
Bit[1] A1
Bit[2] A2
Bit[3] A3
Bit[4] A4
Bit[5] A5
Bit[6] A6
Bit[7] A7
Default = 0x30
on HARD RESET,
SOFT RESET, VCC
POR and VTR POR
Note Bit[0] must be “0”.
OPERATIONAL DESCRIPTION
MAXIMUM GUARANTEED RATINGS*
Operating Temperature Range.....................................................................................................0oC to +70oC
Storage Temperature Range.....................................................................................................-55o to +150oC
Lead Temperature Range ..........................................................................Refer to JEDEC Spec. J-STD-020
Positive Voltage on any pin, with respect to Ground.......................................................................... Vcc+0.3V
Negative Voltage on any pin, with respect to Ground.............................................................................. -0.3V
Maximum Vcc............................................................................................................................................... +7V
*Stresses above those listed above could cause permanent damage to the device. This is a stress rating only and
functional operation of the device at any other condition above those indicated in the operation sections of this
specification is not implied.
Note: When powering this device from laboratory or system power supplies, it is important that the Absolute Maximum
Ratings not be exceeded or device failure can result. Some power supplies exhibit voltage spikes on their outputs when
the AC power is switched on or off. In addition, voltage transients on the AC power line may appear on the DC output.
If this possibility exists, it is suggested that a clamp circuit be used.
DC ELECTRICAL CHARACTERISTICS
(TA = 0°C - 70°C, Vcc = +3.3 V ± 10%)
PARAMETER
I Type Input Buffer
SYMBOL
MIN
2.0
TYP
MAX
UNITS
COMMENTS
Low Input Level
VILI
VIHI
0.8
V
V
TTL Levels
High Input Level
IS Type Input Buffer
Low Input Level
High Input Level
VILIS
VIHIS
VHYS
0.8
V
V
Schmitt Trigger
Schmitt Trigger
2.2
Schmitt Trigger Hysteresis
Input Leakage, I and IS
Buffers
100
mV
Low Input Leakage
High Input Leakage
IIL
-10
-10
+10
+10
VIN = 0
μA
μA
IIH
VIN = VCC
Page 159
