REG OFFSET
NAME
PME_EN4
(hex)
0D
DESCRIPTION
PME Wake Enable Register 4
This register is used to enable individual LPC47M10x PME
wake sources onto the nIO_PME wake bus.
When the PME Wake Enable register bit for a wake source
is active (“1”), if the source asserts a wake event so that
the associated status bit is “1” and the PME_En bit is “1”,
the source will assert the nIO_PME signal.
When the PME Wake Enable register bit for a wake source
is inactive (“0”), the PME Wake Status register will indicate
the state of the wake source but will not assert the
nIO_PME signal.
Default = 0x00
on VTR POR
(R/W)
Bit[0] GP30
Bit[1] GP31
Bit[2] GP32
Bit[3] GP33
Bit[4] GP41
Bit[5] GP43
Bit[6] GP60
Bit[7] GP61
The PME Wake Enable register is not affected by Vcc
POR, SOFT RESET or HARD RESET.
PME Wake Enable Register 5
PME_EN5
0E
This register is used to enable individual LPC47M10x PME
wake sources onto the nIO_PME wake bus.
When the PME Wake Enable register bit for a wake source
is active (“1”), if the source asserts a wake event so that
the associated status bit is “1” and the PME_En bit is “1”,
the source will assert the nIO_PME signal.
When the PME Wake Enable register bit for a wake source
is inactive (“0”), the PME Wake Status register will indicate
the state of the wake source but will not assert the
nIO_PME signal.
Default = 0x00
on VTR POR
(R/W)
Bit[0] GP50
Bit[1] GP51
Bit[2] GP52
Bit[3] GP53
Bit[4] GP54
Bit[5] GP55
Bit[6] GP56
Bit[7] GP57
The PME Wake Enable register is not affected by Vcc
POR, SOFT RESET or HARD RESET.
Reserved – reads return 0
N/A
0F
(R)
10
SMI_STS1
SMI Status Register 1
This register is used to read the status of the SMI inputs.
The following bits must be cleared at their source.
Bit[0] Reserved
Default = 0x02
on VTR POR
(R/W)
Bit[1] PINT. The parallel port interrupt defaults to ‘1’ when
the parallel port activate bit is cleared. When the parallel
port is activated, PINT follows the nACK input.
Bit[2] U2INT
Bit 1 is set to ‘1’ on
VCC POR, VTR
POR, hard reset and
soft reset
Bit[3] U1INT
Bit[4] FINT
Bit[5] MPU-401 INT
Bit[6] Reserved
Bit[7] Reserved (Note 7)
Page 124
