ST7565S
(2) Data Display
End of initialization
Function setup by command input (User
setup)
(2) Display start line set *9
(3) Page address set *10
(4) Column address set *11
Function setup by command input (User
setup)
(6) Display data write *12
Function setup by command input (User
setup)
(1) Display ON/OFF *13
End of data display
Notes: Reference items
*9: Command Description; Display start line set
*10: Command Description; Page address set
*11: Command Description; Column address set
*12: Command Description; Display data write
*13: Command Description; Display ON/OFF
Avoid displaying all the data at the data display start (when the display is ON) in white.
(3) Power OFF *14
Optional status
Set the time (
active to turning off the VDD
SS power (VDD - VSS = 1.8V)
t
L) from reset
-
V
Function setup by command input (User
setup)
(20) Power save *15
longer than the time (
the potential of V
t
H
5
) when
~ V
1
becomes below the threshold
voltage (approximately 1V) of
the LCD panel. For
the <Reference Data> of this
event. When is too long,
t
H, refer to
Reset active (/RES pin = “L”)
t
H
insert a resistor between V
and VDD to reduce it.
5
V
DD – VSS power OFF
Notes: Reference items
*14: The logic circuit of this IC’s power supply VDD - VSS controls the driver of the LCD power supply VDD - V
power supply VDD - VSS is cut off when the LCD power supply VDD - V has still any residual voltage, the driver (COM.
SEG) may output any uncontrolled voltage. When turning off the power, observe the following basic procedures:
• After turning off the internal power supply, make sure that the potential V ~ V has become below the threshold
5. So, if the
5
5
1
voltage of the LCD panel, and then turn off this IC’s power supply (VDD - VSS). 6. Description of Function, 6.7 Power
Circuit
*15: After inputting the power save command, be sure to reset the function using the /RES terminal until the power supply
V
DD - VSS is turned off. 7. Command Description (20) Power Save
*16: After inputting the power save command, do not reset the function using the /RES terminal until the power supply
DD - VSS is turned off. 7. Command Description (20) Power Save
V
Ver 0.6c
55/72
2009/09/07
