SiI 1161 PanelLink Receiver
Data Sheet
June 2005
General Description
Features
The SiI 1161 receiver uses PanelLink Digital
technology to support high-resolution displays up to
UXGA (25-165MHz). This receiver supports up to true
color panels (24 bits per pixel, 16M colors) with both
one and two pixels per clock.
•
•
Supports 10 meter cables at UXGA speed
I2C port for dynamic optimization of settings to
compensate for long cables and/or poor quality
transmitters
Flexible output drive controls to optimize timings
for all possible configurations
3.3V operation
Time staggered data output for reduced ground
bounce and lower EMI
Sync Detect feature for DVI “Hot Plugging”
ESD tolerant to 5kV (HBM) on all pins
Compliant with DVI 1.0
Guaranteed interoperability with DVI-compliant
transmitters
Low power standby mode; automatic entry into
standby mode with clock detect circuitry
Pb-free packaging (see page 41).
•
All PanelLink products are designed on a scaleable
CMOS architecture, ensuring support for future
performance enhancements while maintaining the
same logical interface. System designers can be
assured that the interface will be stable through a
number of technology and performance generations.
•
•
•
•
•
•
PanelLink Digital technology simplifies PC and display
interface design by resolving many of the system level
issues associated with high-speed mixed signal
design, providing the system designer with a digital
interface solution that is quicker to market and lower in
cost.
•
•
SiI 1161 Pin Diagram
ODD 8-bits GREEN
ODD 8-bits BLUE
ODD 8-bits RED
OGND
QO23
OVCC
AGND
RX2+
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
QO1
QO0
HSYNC
VSYNC
DE
RX2-
OGND
ODCK
OVCC
CTL3
CTL2
CTL1
GND
OUTPUT
CLOCK
AVCC
AGND
AVCC
RX1+
SiI 1161
RX1-
100-Pin
TQFP
AGND
AVCC
AGND
RX0+
VCC
QE23
QE22
QE21
QE20
QE19
QE18
QE17
QE16
OVCC
OGND
QE15
QE14
(Top View)
RX0-
AGND
RXC+
RXC-
AVCC
EXT_RES
PVCC
PGND
MODE
SCL
(OCK_INV)
PWR
MGMT
CONFIG. PINS
EVEN 8-bits BLUE
EVEN 8-bits GREEN
SiI-DS-0096-D
SILICONIMAGE [ Silicon image ]
