SiI 1161 PanelLink Receiver
Data Sheet
Calculating Setup and Hold Times
Output setup and hold times between video output clock (ODCK) and video data (including HSYNC, VSYNC and
DE) are functions of the worst case duty cycle specification for ODCK and the worst case clock to output delay.
For the SiI 1161 output pins, only the minimum output setup and hold times are critical.
The SiI 1161 provides the OCK_INV feature, described on page 22, to allow external logic to decode data with
either a rising or falling clock edge.
OCK_INV=0 Case
For OCK_INV=0, the worst-case setup time occurs when the clock to output delay is at a maximum (latest data)
and the ODCK duty cycle is at a minimum (earliest falling edge). Conversely, the worst case hold time occurs
when the clock to output delay is at a minimum (earliest next data) and the ODCK duty cycle is at a maximum
(latest falling edge). This is shown in Figure 5. The falling active ODCK edge is shown with an arrowhead.
Rising edge used
Internal
internally to clock
Clock
out Data (Q), DE,
VSYNC, HSYNC
TDLY - inverter delays
Q
DE
VSYNC
HSYNC
TCK2OUT
= max
TCK2OUT
= min
50%
THD
TSU
T
DUTY= max
TDUTY= min
External clock
ODCK
50%
with
OCK_INV=0
External logic uses
this falling clock edge
to sample data
Figure 5. Receiver Output Setup and Hold Times – OCK_INV=0
Note: For Staggered Output timing in 2Pix/clk mode, refer to Figure 15.
Actual setup and hold times can be derived from the clock period at the operating frequency of interest. Clock
duty cycle must also be taken into account when calculating setup and hold times.
Setup Time to ODCK: TODCK*TDUTY{min} - TCK2OUT{max}
Hold Time from ODCK: TODCK* (1 - TDUTY{max}) + TCK2OUT{min}
