SiI 1161 PanelLink Receiver
Data Sheet
The output drive specifications in the Compatible mode are equivalent to the drive on the SiI 161B part.
Table 3. SiI 161B Mode DC Specifications
Strap option: ST=0 (Low Drive Strength)
Parameter
Conditions
VOUT
Limits (mA)
Typ Max
Notes
ST
CL
Min
Data and Controls
IOHD
IOLD
Output High Drive
Output Low Drive
0
0
0
2.4V
0.8V
0.4V
5pF
5pF
5pF
3.8
5.5
3.2
1
2
3
ODCK and DE
IOHC Output High Drive
IOLC Output Low Drive
0
0
0
2.4V 10pF
0.8V 10pF
0.4V 10pF
7.5
11.1
6.2
4
Strap option: ST=1 (High Drive Strength)
Parameter
Conditions
VOUT
Limits (mA)
Typ Max
Notes
ST
CL
Min
Data and Controls
IOHD
IOLD
Output High Drive
Output Low Drive
1
1
1
2.4V 10pF
0.8V 10pF
0.4V 10pF
7.4
11.1
6.3
1
2
3
ODCK and DE
IOHC Output High Drive
IOLC Output Low Drive
1
1
1
2.4V 20pF
0.8V 20pF
0.4V 20pF
14.7
21.2
12.3
4
Notes
1. Output loading is equivalent to one or two CMOS input loads.
2. 0.8V corresponds to LVTTL VIN(max).
3. 0.4V corresponds to LVCMOS VIN(max).
4. Output loading is equivalent to two or four CMOS input loads.
7
