SC9821C
CD ELECTRONIC SHOCKPROOF CONTROLLER
DESCRIPTION
SC9821C is
function.
a
kind of CD player with electronicshoacnkti•
FEATURES
* Provide 4 compress modes: 16:4, 16:5, 16:6 and non•compress
mode
* Provide
3 pairs data, 2 pairs data and direct comp
LQPF•64•10x10•0.5
connect three comparison connect modes.
* Serial host interface
* Support CD•DA straight in mode
* Support SDRAM/DRAM interface
* Only need one external 16.9344MHz crystal oscillator
* Support various play functions: skip forward/backward in track
skip forward/backward between tracks, pause, and play and so
on.
ORDERING INFORMATION
Device
Package
SC9821C
LQFP•64•10X10•0.5
* Support 1M/4M/8M/16Mx16 SDRAM, 1M/4M x16 DRAM
APPLICATIONS
* CD
BLOCK DIAGRAM
HANGZHOU SILAN MICROELECTRONICS CO.,LTD
REV:1.0
2006.07.21
Page 1 of 18
