EFM32G Data Sheet
Pin Definitions
5. Pin Definitions
Note: Please refer to the application note "AN0002 EFM32 Hardware Design Considerations" for guidelines on designing Printed Cir-
cuit Boards (PCBs) for the EFM32G.
5.1 EFM32G200 & EFM32G210 (QFN32)
5.1.1 Pinout
The EFM32G200 and EFM32G210 pinout is shown in the following figure and table. Alternate locations are denoted by "#" followed by
the location number (Multiple locations on the same pin are split with "/"). Alternate locations can be configured in the LOCATION bit-
field in the *_ROUTE register in the module in question.
Figure 5.1. EFM32G200 & EFM32G210 Pinout (top view, not to scale)
silabs.com | Building a more connected world.
Rev. 2.10 | 79
