C8051F52x-53x
SFR Definition 5.1. ADC0MX: ADC0 Channel Select
R
-
R
-
R
-
R/W
Bit4
R/W
Bit3
R/W
AD0MX
Bit2
R/W
Bit1
R/W
Bit0
Reset Value
00011111
SFR Address:
0xBB
Bit7
Bit6
Bit5
Bits7–5: UNUSED. Read = 000b; Write = don’t care.
Bits4–0: AD0MX4–0: AMUX0 Positive Input Selection
AD0MX4–0
00000
00001
00010
00011
ADC0 Input Channel
P0.0
P0.1
P0.2
P0.3
00100
00101
00110
P0.4
P0.5
P0.6*
P0.7*
P1.0*
P1.1*
P1.2*
P1.3*
P1.4*
P1.5*
P1.6*
P1.7*
00111
01000
01001
01010
01011
01100
01101
01110
01111
11000
Temp Sensor
V
11001
DD
11010 - 11111
GND
*Note: Only applies to C8051F53x parts.
Rev. 0.3
49
