LOW CURRENT CONSUMPTION HIGH RIPPLE-REJECTION LOW DROPOUT CMOS VOLTAGE REGULATOR
Rev.2.3_01
S-1312 Series
Absolute Maximum Ratings
Table 10
(Ta = +25°C unless otherwise specified)
Item
Symbol
Absolute Maximum Rating
Unit
V
VIN
VON / OFF
VOUT
VSS − 0.3 to VSS + 6.0
VSS − 0.3 to VSS + 6.0
VSS − 0.3 to VIN + 0.3
180
Input voltage
V
Output voltage
Output current
SOT-23-5
V
IOUT
mA
mW
mW
mW
°C
600*1
340*1
335*1
Power dissipation HSNT-4 (1010) PD
HSNT-4 (0808)
Operation ambient temperature
Storage temperature
Topr
Tstg
−40 to +85
−40 to +125
°C
*1. When mounted on board
[Mounted board]
(1) Board size:
(2) Name:
114.3 mm × 76.2 mm × t1.6 mm
JEDEC STANDARD51-7
Caution The absolute maximum ratings are rated values exceeding which the product could suffer physical
damage. These values must therefore not be exceeded under any conditions.
1200
1000
HSNT-4 (1010)
HSNT-4 (0808)
SOT-23-5
800
600
400
200
0
100
150
50
0
Ambient Temperature (Ta) [°C]
Figure 8 Power Dissipation of Package (When Mounted on Board)
