LOW CURRENT CONSUMPTION HIGH RIPPLE-REJECTION LOW DROPOUT CMOS VOLTAGE REGULATOR
Rev.2.3_01
S-1312 Series
4. 4 S-1312 Series D type
ON / OFF logic:
Active "H"
Discharge shunt function:
Unavailable
Pull-down resistor:
Table 6
Unavailable
SOT-23-5
HSNT-4 (1010)
HSNT-4 (0808)
Output Voltage
1.0 V 15 mV
1.1 V 15 mV
1.2 V 15 mV
1.3 V 15 mV
1.4 V 15 mV
1.5 V 1.0%
1.6 V 1.0%
1.7 V 1.0%
1.8 V 1.0%
1.85 V 1.0%
1.9 V 1.0%
2.0 V 1.0%
2.1 V 1.0%
2.2 V 1.0%
2.3 V 1.0%
2.4 V 1.0%
2.5 V 1.0%
2.6 V 1.0%
2.7 V 1.0%
2.8 V 1.0%
2.85 V 1.0%
2.9 V 1.0%
3.0 V 1.0%
3.1 V 1.0%
3.2 V 1.0%
3.3 V 1.0%
3.4 V 1.0%
3.5 V 1.0%
S-1312D10-M5T1U3
S-1312D11-M5T1U3
S-1312D12-M5T1U3
S-1312D13-M5T1U3
S-1312D14-M5T1U3
S-1312D15-M5T1U3
S-1312D16-M5T1U3
S-1312D17-M5T1U3
S-1312D18-M5T1U3
S-1312D1J-M5T1U3
S-1312D19-M5T1U3
S-1312D20-M5T1U3
S-1312D21-M5T1U3
S-1312D22-M5T1U3
S-1312D23-M5T1U3
S-1312D24-M5T1U3
S-1312D25-M5T1U3
S-1312D26-M5T1U3
S-1312D27-M5T1U3
S-1312D28-M5T1U3
S-1312D2J-M5T1U3
S-1312D29-M5T1U3
S-1312D30-M5T1U3
S-1312D31-M5T1U3
S-1312D32-M5T1U3
S-1312D33-M5T1U3
S-1312D34-M5T1U3
S-1312D35-M5T1U3
S-1312D10-A4T2U3
S-1312D11-A4T2U3
S-1312D12-A4T2U3
S-1312D13-A4T2U3
S-1312D14-A4T2U3
S-1312D15-A4T2U3
S-1312D16-A4T2U3
S-1312D17-A4T2U3
S-1312D18-A4T2U3
S-1312D1J-A4T2U3
S-1312D19-A4T2U3
S-1312D20-A4T2U3
S-1312D21-A4T2U3
S-1312D22-A4T2U3
S-1312D23-A4T2U3
S-1312D24-A4T2U3
S-1312D25-A4T2U3
S-1312D26-A4T2U3
S-1312D27-A4T2U3
S-1312D28-A4T2U3
S-1312D2J-A4T2U3
S-1312D29-A4T2U3
S-1312D30-A4T2U3
S-1312D31-A4T2U3
S-1312D32-A4T2U3
S-1312D33-A4T2U3
S-1312D34-A4T2U3
S-1312D35-A4T2U3
S-1312D10-A4T1U3
S-1312D11-A4T1U3
S-1312D12-A4T1U3
S-1312D13-A4T1U3
S-1312D14-A4T1U3
S-1312D15-A4T1U3
S-1312D16-A4T1U3
S-1312D17-A4T1U3
S-1312D18-A4T1U3
S-1312D1J-A4T1U3
S-1312D19-A4T1U3
S-1312D20-A4T1U3
S-1312D21-A4T1U3
S-1312D22-A4T1U3
S-1312D23-A4T1U3
S-1312D24-A4T1U3
S-1312D25-A4T1U3
S-1312D26-A4T1U3
S-1312D27-A4T1U3
S-1312D28-A4T1U3
S-1312D2J-A4T1U3
S-1312D29-A4T1U3
S-1312D30-A4T1U3
S-1312D31-A4T1U3
S-1312D32-A4T1U3
S-1312D33-A4T1U3
S-1312D34-A4T1U3
S-1312D35-A4T1U3
Remark Please contact our sales office for products with specifications other than the above.
