K9F5608Q0C
K9F5608D0C
K9F5608U0C
K9F5616Q0C
K9F5616D0C
K9F5616U0C
FLASH MEMORY
COPY-BACK PROGRAM OPERATION
CLE
CE
tWC
WE
tWB
tWB
tPROG
ALE
tR
RE
I/Ox
8Ah
00h
Col. Add
Row Add1 Row Add2
70h
I/O0
A0~A7 A9~A16 A17~A24
Program
Column
Address
Column
CommandAddress
Read Status
Command
Page(Row)
Address
Page(Row)
Address
R/B
I/O0=0 Successful Program
I/O0=1 Error in Program
Busy
Busy
BLOCK ERASE OPERATION (ERASE ONE BLOCK)
CLE
CE
tWC
WE
tBERS
tWB
ALE
RE
I/Ox
A9~A16
A17~A24
60h
DOh
70h
I/O 0
Page(Row)
Address
Busy
R/B
I/O0=0 Successful Erase
Read Status I/O0=1 Error in Erase
Command
Auto Block Erase
Setup Command
Erase Command
