S/UNI®-8x155 ASSP Telecom Standard Product Data Sheet
Released
Expect
01
Receive
XX
Action Declared
Match
XX
XX
00
01
Unequipped
Match
XX
XX
XX
YY
Match
Mismatch
EPSL[7:0] should be reprogrammed with the value 0x13 when receiving ATM payload data.
EPSL[7:0] should be reprogrammed with the value 0x16 when receiving scrambled packet
over SONET payload data.
EPSL[7:0] may be reprogrammed with the value 0xCF when receiving unscrambled packet
over SONET payload data. However, POS scrambling in the RXFP block must be turned
off.
