NCP1207
DRIVER
current sense comparator permanently resets the latch and the
next clock cycle (given by the demagnetization detection) is
ignored: we are skipping cycles as shown by Figure 20. As
soon as the feedback voltage goes up again, there can be two
situations: the recurrent period is small and a new
demagnetization detection (next wave) signal triggers the
NCP1207. To the opposite, in low output power conditions, no
more ringing waves are present on the drain and the toggling
of the current sense comparator together with the internal 5 ms
timeout initiates a new cycle start. In normal operating
conditions, e.g. when the drain oscillations are generous, the
demagnetization comparator can detect the 50 mV crossing
and gives the “green light”, alone, to re−active the power
switch. However, when skip cycle takes place (e.g. at low
output power demands), the re−start event slides along the
drain ringing waveforms (actually the valley locations) which
decays more or less quickly, depending on the
DRIVER = HIGH ? I = 0
DRIVER = LOW ? I = 200 mA
R
skip
3
2
−
+
RESET
R
sense
+
Figure 19. A patented method allows for skip level
selection via a series resistor inserted in series
with the current
The skip level selection is done through a simple resistor
inserted between the current sense input and the sense element.
Every time the NCP1207 output driver goes low, a 200 mA
source forces a current to flow through the sense pin
(Figure 19): when the driver is high, the current source is off
and the current sense information is normally processed. As
soon as the driver goes low, the current source delivers 200 mA
L
−C
network damping factor. The situation can
primary parasitic
thus quickly occur where the ringing becomes too weak to be
detected by the demagnetization comparator: it then
permanently stays locked in a given position and can no longer
deliver the “green light” to the controller. To help in this
situation, the NCP1207 implements a 5 ms timeout generator:
each time the 50 mV crossing occurs, the timeout is reset. So,
as long as the ringing becomes too low, the timeout generator
starts to count and after 5 ms, it delivers its “green light”. If the
skip signal is already present then the controller re−starts;
otherwise the logic waits for it to set the drive output high.
Figure 20 depicts these two different situations:
and develops a ground referenced voltage across R . If this
skip
voltage is below the feedback voltage, the current sense
comparator stays in the high state and the internal latch can be
triggered by the next clock cycle. Now, if because of a low load
mode the feedback voltage is below R
level, then the
skip
Drain
Signal
Timeout
Signal
Demag Re−start
Current Sense and Timeout Re−start
Drain
Signal
Timeout
Signal
5 ms
5 ms
Figure 20. When the primary natural ringing becomes too low, the internal timeout together with the sense
comparator initiates a new cycle when FB passes the skip level.
http://onsemi.com
10
