H8PS
Operation (Run Mode)
Starting Operation
• Set the mode switch to RUN to start operation.
Mode
All Protection Function
The all protection function locks the H8PS in Run Mode and prohibits
any changes to settings. It can be used to prevent incorrect or
unauthorized operation. If the
ADV
Run Mode, the All Protection indicator
and all keys and switches will be disabled. If the mode switch is
changed to Programming or Test Mode while protection is enabled,
Key is pressed for at least 5 s in
PRGM
TEST
RUN
will light on the display
the All Protection indicator
cannot be changed. If a setting on the DIP switch is changed while
protection is enabled, the All Protection indicator will flash when
the power supply is turned ON to indicate that settings cannot be
changed.
will flash to indicate that settings
1
2
7
RUN
Start input
indication
(See note.)
Present angular position
Speed (r/min)
All Protection Function Disabled (Normal Operation)
1
2
4
5
6
STEP
CAM
RUN
Note: For 16/32-output models, be sure that the start input is ON
and that the start input indicator is lit. Outputs (including
the cam, pulse, and run outputs) will not function if the
start input is OFF. The 8-output models do not have a
start input.
Switching the Angle and Speed Displays
STEP
CAM
ON↑ ↓OFF
• Press the
Key for at least 1 s in Run Mode to reverse the
Press the ADV Key for 5 s min.
display positions of the present angular position and speed (r/min)
between main display and sub-display.
1
2
7
All Protection Function Enabled
RUN
1
2
4
5
6
All protection indication
RUN
Present angular position on main display
Speed (r/min) on sub-display
ON↑ ↓OFF
STEP
Press the
Key for 1 s min.
CAM
Checking ON/OFF Angle Settings
1
2
7
• During Run Mode, the CAM Keys
and STEP Keys
RUN
can be used to check the ON/OFF angle settings for any step. Also,
the
Key can be pressed to check the ON/OFF angle
CHECK
Speed (r/min) on main display
settings in order for all steps starting from cam 1. If there is no key
operation for 10 s or longer during the checking operation, the
previous display will be resumed.
Present angular position on sub-display
24
