H8PS
Pulse Output (f1/f2)
Speed Alarm Outputs (f3/f4)
Outputs a preset number of pulses per Encoder rotation. Pulses are
output at a 1:1 ON/OFF ratio and pulse output can be started from a
specified angle.
Specific cam outputs can be used as Encoder speed alarm outputs.
Alarms can be output for upper and lower speed limits.
Speed
Operation for 9 Output Pulses and a Start Angle of 0°
Upper limit SV
1
2
3
4
5
6
7
8
9
Lower limit SV
0°
90°
180°
270°
0°
0°
Upper Limit Alarm Output
Output start angle
Operation for 9 Output Pulses and a Start Angle of 10°
Lower Limit Alarm Output
1
2
3
4
5
6
7
8
9
The speed alarm outputs are assigned to cam outputs as shown in
the following table. The speed alarms are set to “- - -” for the default
settings, i.e., the normal cam outputs are enabled. If a speed alarm is
set to any value but “- - -”, the normal cam output for the
corresponding cam number will be disabled.
0°10°
90°
Output start angle
180°
270°
Number of Output Pulses (f1)
Select the number of pulses per rotation from the following table.
Upper Limit
Lower Limit
Alarm Output
Alarm Output
Encoder resolution
Settable number of pulses
H8PS-8@ (8 outputs)
H8PS-16@ (16 outputs) Cam 15
H8PS-32@ (32 outputs) Cam 31
Cam 7
Cam 8
256
1, 2, 3, 4, 5, 6, 9, 10, 12, 15, 18, 20,
Cam 16
Cam 32
30, 36,
1, 2, 3, 4, 5, 6, 9, 10, 12, 15, 18, 20,
30, 36, 45, 60 , 90, 180
45, 60 ,
90
360
720
The setting ranges for the upper and lower limits speed alarm are
given in the following table.
1, 2, 3, 4, 5, 6, 8, 9, 10, 12, 15, 18, 20, 24,
30, 36, 40, 45, 60 , 72, 90, 120, 180, 360
Encoder resolution
Speed
” or 0 to 1,600 r/min
” or 0 to 800 r/min
Note: Default settings are shown in reverse type.
- - -
- - -
256, 360
720
“
“
Example: Setting 90 Pulses per Rotation
The number of pulses is set using the F1 menu in the Function
Setting Mode.
Note: Default settings are shown in reverse type.
Speed Alarm Upper Limit (f3)
Setting Display
Example: Setting the Upper Limit Set Value to 700 r/min for a 16-
output Model
PRG
Set the number of pulses with the
The upper limit set value is set using the F3 menu in the Function
Setting Mode.
ANGLE Keys
and then press the
Key.
WRITE
Upper Limit Setting Display
STEP
CAM
PRG
Pulse Output Start Angle (f2)
Set the upper limit set value to 700 with
the ANGLE Keys
and then press
The setting ranges are given in the following table.
the Key. (See note.)
WRITE
Encoder
Start angle
Resolution Display
angle
STEP
CAM
256
256
360
720
256
360
---
0 to 255°
0 to 359° (See note 2.)
0 to 359°
Note: If banks are being used, the bank number must be set.
Speed Alarm Lower Limit (f4)
---
0 to 359.5°
Example: Setting the Lower Limit Set Value to 20 r/min for a 16-
output Model
Note: 1. Default settings are shown in reverse type.
2. The output accuracy is 2° maximum, so not all angles can
The lower limit set value is set using the F4 menu in the Function
Setting Mode.
be set.
Example: Setting the Pulse Output Start Angle to 100°
Lower Limit Setting Display
The starting angle for pulse outputs is set using the F2 menu in the
Function Setting Mode.
PRG
Set the upper limit set value to 20 with
Setting Display
the ANGLE Keys
and then press
the Key.
WRITE
PRG
Set the pulse output start angle to 100
STEP
CAM
with the ANGLE Keys
and then
Note: If banks are being used, the bank number must be set.
press the Key.
WRITE
CAM
STEP
28
