H8PS
Encoder Connecting Direction
H8PS-8B@
H8PS-8BF@
H8PS-16BF@
H8PS-32BF@
H8PS-16B@
H8PS-32B@
Encoder
Encoder
Output cable
Encoder
Encoder
Output cable
■ Accessories (Order Separately)
• Panel Surface Mounting
Parallel Input Adapters
Front
Y92C-30
M4 screw (included)
This Adapter enables two H8PS Cam Positioners to share signals
from an Encoder.
Note: H8PS has been improved in 2004 April.
Do not mix old and new model with Y92C-30.
When you use 2 x H8PS, please use by "Old & Old" or "New &
New" models.
1
74
Two, M4 tap holes
36
• Panel Back Mounting
Back
M4 nut (included)
M4 screw (included)
Connected to the H8PS.
Connected to the H8PS.
1
74
Y92C-30
Two, 4.3 dia. holes
36
From the Dedicated Absolute Encoder
Use the cable marked with a triangle when connecting only one
H8PS Cam Positioner to the Parallel Input Adapter.
9
47
1,030
40.4
6.5
15
37
8.5 dia.
17 dia.
26
89 60 24
R6.5
36 14 dia.
11.3
13
